Logic gates

Logic gates are an integral part of today's digital technology. According to digital technology, data processing, storage and exchange are carried out using an electrical conductor. When there is electricity (+Vs) and when there is no electricity (0V) then all the data is represented by 1 and 0. Logic gates are used to switch the flow of electricity (electrical signals) i.e. to switch the flow of electricity on or off. Quite logical

The functions of portals include allowing electricity to travel, preventing it from traveling or providing electricity when there is no electricity. The same logic gate operation can be implemented in the same way as the logic gate operation can be implemented.

A logic gate is made up of several transistors. Although the process of a single transistor is similar to that of a NOT gate, practically the NOT gate is not made of a single transistor.

Several combinations are specified to enable the same logic gate operation. The logic gates of these circuits are recorded in electronic circuits.

There are seven basic logic gates

1. AND

2. OR

3. NOT

4. NAND

5. NOR

6. XOR

7. XNOR

AND logic gate
